Senther Technology 540B
- Part Number:
540B
- Manufacturer:
- Category:
- RoHs:
RoHS Compliant - Datasheet:
540B_Datesheet - Description:
EMBEDDED PIEZOELECTRIC ACCELEROM
- In stock 81
DESCRIPTION
· The 540B is a miniature, low-power vibration sensor designed for embedded condition monitoring.
· It incorporates the latest piezoelectric (PE) technology for superior signal-to-noise ratio and frequency response.
· The annular shear PE structure ensures stable output and ultra-low noise density over an extended frequency range.
· It has a noise density of 8 µg/√Hz and consumes 60uA current.
· The sensor is immune to external shocks up to 5000g and operates in a temperature range of −55°C to +150°C.
· It is available in a 10mm × 10mm × 5.5mm SMD package.
FEATURES
· Annular shear structure for stability.
· Wide frequency response: 0.5Hz to 28 kHz (±3dB).
· Low noise: 8 µg/√Hz @1kHz.
· Linearity ±0.5% up to 500g range.
· Low power consumption: 0.06 mA.
· Temperature range: −55°C to +150°C.
· Sensitive orientation: vertical to mounting surface.
· Acceleration range: 50~500g full scale.
· Small package: 10mm × 10mm × 5.5mm.
· Reflow solderable.
APPLICATIONS
· Condition monitoring.
· Shock/impact data logging.
· Bear/Gearbox embedding.
· Machine vibration monitoring.
· General test and measurement.
