DESCRIPTION

· 200mW Zener Diode with voltage range from 2.4 to 75 Volts.

· Operating and storage temperature range from -55°C to +150°C.

· Thermal resistance of 625°C/W from junction to ambient.

· Standard Vz tolerance of ±2%.

· Halogen-free, "Green" device compliant with RoHS standards.

· Moisture Sensitivity Level 1 and UL 94 V-0 flammability rating.

FEATURES

· Power dissipation of 200mW.

· Lead-free finish, RoHS compliant.

· Maximum forward voltage of 0.9V at IF=10mA.

· Epoxy meets UL 94 V-0 flammability rating.

· Halogen-free with less than 900ppm bromine and chlorine, and less than 1000ppm antimony compounds.

APPLICATIONS

· Voltage regulation in electronic circuits.

· Protection circuits against overvoltage conditions.

· Suitable for use in environmentally sensitive applications due to its "Green" certification.
