DESCRIPTION

· The MAX 3000A family is a series of high-performance, low-cost CMOS EEPROM-based programmable logic devices (PLDs) built on the MAX architecture.

FEATURES

· 3.3-V in-system programmability (ISP) via IEEE Std. 1149.1 JTAG interface with advanced pin-locking capability.

· Built-in boundary-scan test (BST) circuitry compliant with IEEE Std. 1149.1-1990.

· Enhanced ISP features for faster programming and complete programming assurance.

· High-density PLDs ranging from 600 to 10,000 usable gates.

· 4.5-ns pin-to-pin logic delays with counter frequencies up to 227.3 MHz.

· MultiVolt I/O interface supporting 5.0-V, 3.3-V, and 2.5-V logic levels.

· Package options include TQFP, PQFP, PLCC, and FineLine BGA with pin counts from 44 to 256.

· Hot-socketing support and programmable interconnect array (PIA) for fast, predictable performance.

· Industrial temperature range operation.

APPLICATIONS

· Suitable for high-performance, low-cost programmable logic solutions in various industries.

· Ideal for applications requiring in-system programmability and boundary-scan testing.

· Used in systems needing compatibility with multiple logic levels and high-speed logic delays.

· Applicable in environments requiring robust performance across industrial temperature ranges.
