DESCRIPTION

· The LM29150, LM29151, and LM29152 are high-current, high-accuracy, low-dropout voltage regulators.

· They utilize a PNP pass element, featuring a 350mV dropout voltage at full load and very low ground current.

· These devices are suitable for low-current, low-dropout critical systems due to their minimal dropout voltage and ground current.

· They offer full protection against over-current faults, reversed input polarity, reversed lead insertion, over-temperature operation, and transient voltage spikes.

· The LM29151 includes logic-level enable control and an error flag indicating when the output is out of regulation.

· The ENABLE pin on LM29151 and LM29152 can be tied to Vin if ON/OFF control is not needed.

FEATURES

· High current capability of 1.5A.

· Low dropout voltage of 350mV.

· Low ground current.

· Accurate 1% initial tolerance.

· Extremely fast transient response.

· Reverse-battery and load dump protection.

· Zero-current shutdown mode (5-pin version).

· Error flag signals output out-of-regulation (5-pin version).

· Characterized for smaller loads with industry-leading performance.

· Available in fixed and adjustable voltage versions.

· Moisture Sensitivity Level 3.

APPLICATIONS

· Battery-powered equipment.

· High-efficiency "Green" computer systems.

· Automotive electronics.

· High-efficiency linear power supplies.

· High-efficiency post-regulator for switching supplies.
