DESCRIPTION

· The MCP73833/4 is a linear charge management controller designed for space-limited, cost-sensitive applications.

· It supports Lithium-Ion and Lithium-Polymer battery charging with a constant current/constant voltage algorithm.

· Available in 10-Lead DFN and MSOP packages, it requires minimal external components, making it ideal for portable devices.

· It adheres to USB power bus specifications for USB port charging applications.

· Operates within an ambient temperature range of -40°C to +85°C.

FEATURES

· Integrated pass transistor, current sense, and reverse discharge protection.

· High accuracy preset voltage regulation options: 4.2V, 4.35V, 4.4V, or 4.5V, ±0.75%.

· Programmable charge current up to 1A with thermal regulation.

· Preconditioning for deeply depleted cells with selectable current ratio and voltage threshold.

· Automatic end-of-charge control with selectable current threshold and safety time period.

· Automatic recharge with selectable voltage threshold.

· Two charge status outputs and cell temperature monitoring.

· Low-dropout linear regulator mode and automatic power-down when input power is removed.

· Under voltage lockout and numerous selectable options for various applications.

APPLICATIONS

· Lithium-Ion / Lithium-Polymer battery chargers.

· Personal Data Assistants, Cellular Telephones, and Digital Cameras.

· MP3 Players, Bluetooth Headsets, and USB Chargers.
