Name: RF3356-TP
Brand: Micro Commercial Co
SKU: JM-RF3356-TP
Availability: InStock

Micro Commercial Co RF3356-TP

View All Bipolar RF Transistors by Micro Commercial Co

Part Number:
RF3356-TP
Manufacturer:
Micro Commercial Co
Category:
Bipolar RF Transistors
RoHs:
Non-RoHS Compliant
Datasheet:
RF3356-TP_Datesheet
Description:
Interface
In stock 0

" Not available to buy online? Want the lower wholesale price? Please send RFQ, we will respond immediately

Leave Us A Message!

[email protected]

We`re not around but we still want to hear from you! Leave us a note:

SEND

*You can contact us directly on WhatsApp!

Specifications

Type

Paramete

Type

Paramete

Package / Case

TO-236-3, SC-59, SOT-23-3

DC Current Gain (hFE) (Min) @ Ic, Vce

130 @ 20mA, 10V

Gain

12.5dB

Noise Figure (dB Typ @ f)

1.1dB @ 1GHz

Current - Collector (Ic) (Max)

100mA

Supplier Device Package

SOT-23

Transistor Type

NPN

Grade

Power - Max

150mW

Frequency - Transition

7GHz

Operating Temperature

-55°C ~ 150°C (TJ)

Qualification

Voltage - Collector Emitter Breakdown (Max)

12V

Mounting Type

Surface Mount

Overview

DESCRIPTION

· RF3356 is an NPN RF Transistor with a power dissipation of 150 mW.

· It operates with a collector current of 100 mA and a collector-emitter voltage of 12 V.

· The transistor has a collector-base voltage of 20 V and an emitter-base voltage of 3 V.

· It is designed for use in RF wideband amplifiers and oscillators.

FEATURES

· High power gain and low noise figure.

· High cut-off frequency suitable for RF applications.

· Halogen-free and meets the "Green" device criteria.

· Moisture Sensitivity Level 1 and epoxy meets UL 94 V-0 flammability rating.

· Lead-free finish and RoHS compliant.

APPLICATIONS

· Ideal for RF wideband amplifiers.

· Suitable for use in oscillators within RF circuits.
