DESCRIPTION

· SCR1100-D02 is a single-axis high-performance gyroscope based on VTI's capacitive 3D-MEMS technology.

· It features a sophisticated signal conditioning ASIC with a digital SPI interface.

· Designed for high stability and reliability, it operates effectively across a wide temperature range and in mechanically noisy environments.

· The device is housed in a robust, RoHS-compliant package suitable for SMD mounting.

FEATURES

· Measures angular rate around the X-axis with a range of ±100 º/s.

· Exceptionally insensitive to mechanical vibrations and shocks.

· Superior bias instability for MEMS gyroscopes (<1º/h).

· Compact size: 8.5 x 18.7 x 4.5 mm.

· Enhanced self-diagnostics features.

· Operates in a temperature range of -40 °C to +125 °C.

APPLICATIONS

· Inertial Measurement Units (IMUs) for demanding environments.

· Platform stabilization and control.

· Motion analysis and control.

· Roll-over detection.

· Robotic control systems.

· Guidance and navigation systems.
