XAL6060-562MEC Model Information

Part Number: XAL6060-562MEC

Product Overview:

• Series: XAL60xx
• Description: Shielded Power Inductor
• Inductance: 5.6 µH (±20%)
• DCR: 14.46 mΩ (typ), 15.90 mΩ (max)
• SRF (Self-Resonant Frequency): 20 MHz (typ)
• Isat (Saturation Current): 9.9 A (current causing a 30% drop in inductance)
• Irms (RMS Current): 7.5 A (at 40°C temperature rise)
• Operating Voltage: 0–60 V
• Temperature Range: -40°C to +125°C (ambient), +165°C (maximum part temperature)
• Weight: 1.0–1.6 g
• Termination: RoHS compliant tin-silver (96.5/3.5) over copper
• Special Order Terminations: Tin-silver-copper (95.5/4/0.5) or non-RoHS tin-lead (63/37)
• Packaging: 7″ machine-ready reel, EIA-481 embossed plastic tape; quantities less than full reel available in tape (not machine-ready) or with leader and trailer ($25 charge)
• Features:
• High current capability
• Very low DCR (Direct Current Resistance)
• Soft saturation characteristics
• AEC-Q200 qualified
• RoHS compliant and halogen-free
• Composite core material
• Operating ambient temperature range: -40°C to +125°C with a 40°C temperature rise
• Resistance to soldering heat: Max three 40-second reflows at +260°C, with parts cooled to room temperature between cycles
• Moisture Sensitivity Level (MSL) 1 (unlimited floor life at <30°C / 85% relative humidity)
• PCB washing tested to MIL-STD-202 Method 215 plus an additional aqueous wash
• Applications:
• High-current power supplies
• Automotive electronics
• Industrial power modules
• Telecommunications infrastructure
• Testing and Specifications:
• Inductance tested at 1 MHz, 0.1 Vrms, 0 Adc
• DCR measured using a micro-ohmmeter
• SRF measured using Agilent/HP 4395A or equivalent
• Irms testing performed on 0.75 inch wide × 0.25 inch thick copper traces in still air
• Temperature rise is highly dependent on PCB land pattern, trace size, and proximity to other components; should be verified in application conditions
• Ordering Information:
• Termination Options:E: RoHS compliant tin-silver over copperT: RoHS tin-silver-copper (95.5/4/0.5)S: Non-RoHS tin-lead (63/37)
• Packaging Codes:C: 7″ machine-ready reel, EIA-481 embossed plastic tapeB: Less than full reel (change the last letter of the part number from B to C when ordering)D: 13″ machine-ready reel, EIA-481 embossed plastic tape (factory order only, not stocked)
