Description of Compass and Magnetic Fiels Moudules

Compass and magnetic field modules are devices used to measure and detect the Earth's magnetic field.They generally incorporate magnetometer sensors and data processing units to ascertain the direction and intensity of the magnetic field. These modules find extensive application in navigation systems, geographic information systems (GIS), drones, and smartphones, enabling location positioning and navigation functionalities.

Compass and magnetic field modules

Frequently Asked Questions

What is a magnetometer sensor?

Magnetometers are now widely employed in numerous applications. They measure the Earth's magnetic field, conduct geographical surveys, assist the military in detecting submarines, and are even used in metal/weapons detectors. In recent times, magnetometers have been miniaturized and integrated into circuits at a very affordable cost.

How does a compass show magnetic fields?

A compass enables us to observe the direction of a magnetic field by using compass needles, which are small magnets capable of rotating freely. Typically, compasses align themselves parallel to the Earth's magnetic field lines in response to it.

What is the difference between a magnetometer and a compass?

A magnetic compass is intended to provide a horizontal bearing direction, whereas a vector magnetometer measures both the strength and direction of the overall magnetic field. To measure the components of the magnetic field in all three dimensions, three orthogonal sensors are necessary.
