TE Connectivity AMP Connectors 1-776230-1

memberiso
  • Part Number:

    1-776230-1

  • Manufacturer:

    TE Connectivity AMP Connectors

  • Category:

    Headers, Male Pins

  • RoHs:

    rohs Non-RoHS Compliant

  • Datasheet:

    pdf 1-776230-1_Datesheet

  • Description:

    Connector Header Panel Mount, Through Hole 35 position 0.157" (4.00mm)

  • In stock 69
" Not available to buy online? Want the lower wholesale price? Please send RFQ, we will respond immediately
Contact Name
Business Email
Company Name
Country
Quantity
Email

Leave Us A Message!

We`re not around but we still want to hear from you! Leave us a note:

SEND
EmailWhatsApp
*You can contact us directly on WhatsApp!
Specifications
Type
Paramete
Type
Paramete
Contact Type
Male Pin
Pitch - Mating
0.157" (4.00mm)
Contact Finish Thickness - Post
-
Insulation Height
-
Insulation Material
Polybutylene Terephthalate (PBT), Glass Filled
Mfr
TE Connectivity AMP Connectors
Operating Temperature
-40°C ~ 125°C
Row Spacing - Mating
0.157" (4.00mm)
Style
Board to Cable/Wire
Current Rating (Amps)
Varies by Wire Gauge
Contact Length - Post
-
Insulation Color
Black
Features
Mounting Flange, Sealable
Contact Finish Thickness - Mating
-
Number of Positions Loaded
All
Number of Positions
35
Applications
Automotive, Industrial
Connector Type
Header
Ingress Protection
-
Mounting Type
Panel Mount, Through Hole
Number of Rows
3
Shrouding
Shrouded - 4 Wall
Base Product Number
776230
Overall Contact Length
-
Fastening Type
Locking Ramp
Contact Length - Mating
-
Mated Stacking Heights
-
Contact Material
Brass
Contact Finish - Post
-
Termination
Solder
Material Flammability Rating
-
Contact Shape
Circular
Voltage Rating
250VAC
Contact Finish - Mating
Gold-Palladium
