HARTING 09185106324

memberiso
  • Part Number:

    09185106324

  • Manufacturer:

    HARTING

  • Category:

    Headers, Male Pins

  • RoHs:

    rohs RoHS Compliant

  • Datasheet:

    pdf 09185106324_Datesheet

  • Description:

    Connector Header Through Hole 10 position 0.100" (2.54mm)

  • In stock 1,699
" Not available to buy online? Want the lower wholesale price? Please send RFQ, we will respond immediately
Contact Name
Business Email
Company Name
Country
Quantity
Email

Leave Us A Message!

We`re not around but we still want to hear from you! Leave us a note:

SEND
EmailWhatsApp
*You can contact us directly on WhatsApp!
Specifications
Type
Paramete
Type
Paramete
Shrouding
Shrouded - 4 Wall
Style
Board to Cable/Wire
Applications
-
Contact Shape
Square
Row Spacing - Mating
0.100" (2.54mm)
Features
Keying Slot
Insulation Material
Polybutylene Terephthalate (PBT), Glass Filled
Material Flammability Rating
UL94 V-0
Mated Stacking Heights
-
Ingress Protection
-
Contact Length - Mating
0.240" (6.10mm)
Connector Type
Header
Current Rating (Amps)
-
Insulation Color
Gray
Mfr
HARTING
Termination
Solder
Contact Finish Thickness - Post
-
Contact Finish Thickness - Mating
-
Pitch - Mating
0.100" (2.54mm)
Number of Rows
2
Number of Positions
10
Contact Finish - Mating
Gold
Fastening Type
Latch Holder
Contact Length - Post
0.114" (2.90mm)
Contact Finish - Post
Tin
Number of Positions Loaded
All
Mounting Type
Through Hole
Overall Contact Length
-
Contact Material
Copper Alloy
Operating Temperature
-55°C ~ 125°C
Voltage Rating
-
Contact Type
Male Pin
Insulation Height
0.350" (8.89mm)
