ASP-103614-04 Product Information

Product Overview

The ASP-103614-04 is a VITA 42 (lead-free) socket assembly designed for high-reliability applications. This product is manufactured with precision engineering to meet stringent industry standards, ensuring robust performance in demanding environments.

Detailed Breakdown of Model Number

• ASP-103614-04: This is the specific part number for the VITA 42 (lead-free) socket assembly.

Features

• Lead-Free Design: Complies with environmental regulations and enhances reliability.
• High-Density Interconnects: Suitable for applications requiring high-density and high-reliability connections.
• Precision Engineering: Manufactured to tight tolerances to ensure consistent performance.
• Conductive Polymer: Utilizes conductive polymer for enhanced electrical performance.
• Gold Over Nickel Plating: Features .000030 gold over .000050 nickel plating for superior corrosion resistance and conductivity.
• Polyimide Film: Uses polyimide film for insulation, providing excellent thermal and electrical properties.

Specifications

• Material:Brass Alloy 260: 3/4 hard, used for the socket body.Conductive Polymer: For enhanced electrical performance.Polyimide Film: For insulation.
• Plating:Gold Over Nickel: .000030 gold over .000050 nickel.
• Tolerances:Dimensions: Specified in inches and millimeters.Lead-Free Solder Balls: Comply with environmental standards.
• Packaging:Tape and Reel: Available for quantities of 125 pieces or more.No Trailer or Leader: For quantities less than 125 pieces.

Mechanical Specifications

• Dimensions:Overall Length: 1.050 inches [26.67 mm]Overall Width: 0.900 inches [22.86 mm]Height: 0.420 inches [10.67 mm]
• Lead Pitch: 0.050 inches [1.27 mm]
• Lead Length: 0.350 inches [8.89 mm]
• Lead Width: 0.020 inches [0.51 mm]
• Flash: Maximum 0.010 inches [0.25 mm]
• Pushout Force: Minimum 0.5 lb [2.22 N]

Electrical Specifications

• Conductive Polymer: Ensures reliable electrical connections.
• Gold Over Nickel Plating: Provides superior conductivity and corrosion resistance.

Applications

• High-Reliability Electronics: Suitable for applications requiring high-reliability and high-density interconnects.
• Automotive and Industrial: Ideal for automotive and industrial applications where robust performance is critical.
• Telecommunications: Can be used in telecommunications equipment for reliable signal transmission.

Ordering Information

• Part Number: ASP-103614-04
• Material: Brass Alloy 260, Conductive Polymer, Polyimide Film
• Plating: Gold over Nickel
• Packaging: Tape and reel for quantities of 125 pieces or more; no trailer or leader for quantities less than 125 pieces.
