Qorvo SBB5089Z
- Part Number:
SBB5089Z
- Manufacturer:
- Category:
- RoHs:
RoHS Compliant - Datasheet:
- Description:
- In stock 0
Description
JMBom's SBB5089Z is a high-performance InGaP HBT MMIC amplifier that employs a Darlington topology with an integrated active bias circuit. This active bias system ensures stable current operation across temperature changes and process Beta variations. Designed for direct operation from a 5V power source, the SBB5089Z eliminates the need for a dropping resistor, unlike conventional Darlington amplifiers. Optimized for high-linearity 5V gain block applications, this device features a compact footprint and requires minimal external components. Additionally, it comes with internal 50-ohm matching for ease of integration.
Key Features
• Consistent wideband gain up to 4GHz: ±1.1dB
• Output power at 1dB compression (P1dB) = 20.4dBm at 1950MHz
• Operates on a single fixed 5V supply
• High ESD robustness (1000V, Class 1C)
• Proprietary thermal management design
• Low thermal resistance for improved reliability
Parameters
| Frequency Min(MHz) | 50 |
| Frequency Max(MHz) | 6,000 |
| Gain(dB) | 20.1 |
| OP1dB(dBm) | 20.4 |
| OIP3(dBm) | 35 |
| NF(dB) | 4.2 |
| Voltage(V) | 5 |
| Current(mA) | 75 |
| Package Type | SOT-89 |
