DESCRIPTION

· The TPT772x devices are high-performance, dual-channel enhanced digital isolators with 5000-V RMS (WSOP8, WSOP16) and 3750-V RMS (SOP8) isolation ratings per UL 1577.
· Certified by VDE, UL, CSA, TUV, CQC, and CB.
· Each isolation signal channel is separated by a double capacitive silicon dioxide insulation barrier.
· TPT7720 has both channels in the same direction; TPT7721 has both channels in the opposite direction.
· Fail-safe default output is low for devices with the suffix F and high for devices without the suffix F.
· Available in SOP8, WSOP8, and WSOP16 packages, characterized from −40°C to +125°C.
· Qualified for automotive applications with AEC-Q100 Reliability Test.

FEATURES

· 150-Mbps Data Rate.
· 5-kV RMS Isolation Rating (WSOP).
· ±200-kV/μs typ Static CMTI, ±150-kV/μs typ Dynamic CMTI.
· Low Power Consumption, typ 3 mA/ch @1 Mbps.
· Low Propagation Delay: 12 ns Typical.
· Default Output Low (TPT772xF) and High (TPT772x).
· Wide Temperature Range: −40°C to +125°C.
· SOP8, WSOP8, and WSOP16 Packages.
· Robust Electromagnetic Compatibility (EMC): Low Emissions, System-Level ESD, EFT, and Surge Immunity.
· Safety-Related Certifications: VDE, UL 1577, CQC, CSA, TUV, and CB.

APPLICATIONS

· EV and HEV Electric and Power Train System.
· Motor Control.
· Power Supplies.
· Isolated Interface and General-Purpose Isolation.
