DESCRIPTION

· The 74HCT4538 is a dual retriggerable-resettable monostable multivibrator.

· It features two trigger/retrigger inputs, a direct reset input, and two complementary outputs.

· External timing components CEXT and REXT determine the output pulse duration and accuracy.

· The output pulse width (TW) is calculated as 0.7 × REXT × CEXT.

· It supports triggering by either positive or negative edges of the input pulse.

· Schmitt-trigger action enhances tolerance to slower rise and fall times.

FEATURES

· Tolerant of slow trigger rise and fall times.

· High noise immunity and separate reset inputs.

· Complies with JEDEC standard no. 7A.

· Wide supply voltage range from 4.5 to 5.5 V.

· CMOS low power dissipation and TTL input levels.

· ESD protection: HBM exceeds 2000 V, CDM exceeds 1000 V.

· Specified from -40 °C to +125 °C.

APPLICATIONS

· Precision timing circuits.

· Pulse width modulation systems.

· Noise-tolerant signal processing.

· Industrial control systems.

· Automotive electronics.

· Consumer electronics requiring precise timing.
