ADF4002BCPZ Product Information

Overview

The ADF4002BCPZ is a frequency synthesizer designed for use in wireless receivers and transmitters. It features a low noise digital phase frequency detector (PFD), a precision charge pump, programmable reference divider, and programmable N divider.

Model Information

• Model Number: ADF4002BCPZ
• Temperature Range: -40°C to +85°C
• Package Type: 20-Lead Lead Frame Chip Scale Package (LFCSP)
• Package Option: CP-20-6

Package Dimensions

• Body Size: 4 mm × 4 mm
• Package Height: 0.75 mm
• Lead Pitch: 0.50 mm
• Exposed Pad: Connected to AGND for proper thermal performance

Ordering Information

• Ordering Code: ADF4002BCPZ
• RoHS Compliance: Yes (Z indicates RoHS compliant part)
• Evaluation Board: EV-ADF4002SD1Z

Features

• Frequency Range: Up to 400 MHz
• Power Supply: 2.7 V to 3.3 V
• Charge Pump Supply: Up to 5.5 V
• Programmable Charge Pump Currents
• 3-Wire Serial Interface
• Analog and Digital Lock Detect
• Hardware and Software Power-Down Mode
• 104 MHz Phase Detector

Applications

• Clock Conditioning
• Clock Generation
• IF LO Generation

Additional Information

• Datasheet Revision: Rev. D
• Company: Analog Devices, Inc.
