Name: EL3H7(B)-G
Brand: Everlight Electronics Co Ltd
SKU: JM-EL3H7(B)-G
Availability: InStock

Everlight Electronics Co Ltd EL3H7(B)-G

View All Transistor, Photovoltaic Output Optoisolators by Everlight Electronics Co Ltd

Part Number:
EL3H7(B)-G
Manufacturer:
Everlight Electronics Co Ltd
Category:
Transistor, Photovoltaic Output Optoisolators
RoHs:
RoHS Compliant
Datasheet:
EL3H7(B)-G_Datesheet
Description:
Optoisolator Transistor Output 3750Vrms 1 Channel 4-SSOP
In stock 307

" Not available to buy online? Want the lower wholesale price? Please send RFQ, we will respond immediately

Leave Us A Message!

[email protected]

We`re not around but we still want to hear from you! Leave us a note:

SEND

*You can contact us directly on WhatsApp!

Specifications

Type

Paramete

Type

Paramete

Current - DC Forward (If) (Max)

50 mA

Mounting Type

Surface Mount

Rise / Fall Time (Typ)

5µs, 3µs

Voltage - Output (Max)

80V

Supplier Device Package

4-SSOP

Turn On / Turn Off Time (Typ)

Output Type

Transistor

Vce Saturation (Max)

200mV

Voltage - Forward (Vf) (Typ)

1.2V

Current Transfer Ratio (Max)

260% @ 5mA

Current Transfer Ratio (Min)

130% @ 5mA

Operating Temperature

-55°C ~ 110°C

Base Product Number

EL3H7

Voltage - Isolation

3750Vrms

Current - Output / Channel

50mA

Input Type

Number of Channels

Package / Case

4-SOIC (0.173", 4.40mm Width)

Overview

DESCRIPTION

· The EL3H7-G series devices consist of an infrared emitting diode optically coupled to a phototransistor detector, encapsulated with green compound in a 4-pin small outline SMD package.

FEATURES

· Halogens free (Br <900 ppm, Cl <900 ppm, Br+Cl <1500 ppm).
· Current transfer ratio (CTR: 50~600% at IF=5mA, VCE=5V; CTR: 40~320% at IF=10mA, VCE=5V).
· High isolation voltage between input and output (Viso=3750 V rms).
· Compact 4 Pin SSOP with a 2.0 mm profile.
· Compliance with EU REACH.
· Pb free and RoHS compliant.
· UL and cUL approved (No. E214129).
· VDE approved (No. 132249).
· SEMKO, NEMKO, DEMKO, FIMKO approved.

APPLICATIONS

· DC-DC Converters.
· Programmable controllers.
· Telecommunication equipment.
· Signal transmission between circuits of different potentials and impedances.
