Name: MC74HC393ADTR2G
Brand: onsemi
SKU: JM-MC74HC393ADTR2G
Availability: InStock

onsemi MC74HC393ADTR2G

View All Display Drivers by onsemi

Part Number:
MC74HC393ADTR2G
Manufacturer:
onsemi
Category:
Display Drivers
RoHs:
RoHS Compliant
Datasheet:
MC74HC393ADTR2G_Datesheet
Description:
IC BIN COUNTER DL 4BIT 14TSSOP
In stock 496

" Not available to buy online? Want the lower wholesale price? Please send RFQ, we will respond immediately

Leave Us A Message!

[email protected]

We`re not around but we still want to hear from you! Leave us a note:

SEND

*You can contact us directly on WhatsApp!

Specifications

Type

Paramete

Type

Paramete

Qualification

Supplier Device Package

14-TSSOP

Timing

Count Rate

50 MHz

Reset

Asynchronous

Grade

Logic Type

Binary Counter

Mounting Type

Surface Mount

Number of Bits per Element

Voltage - Supply

2 V ~ 6 V

Package / Case

14-TSSOP (0.173", 4.40mm Width)

Trigger Type

Negative Edge

Direction

Number of Elements

Operating Temperature

-55°C ~ 125°C

Overview

Product Information for MC74HC393ADTR2G

Device:

MC74HC393A

Marking:

HC393AG

Package:

TSSOP-14

Shipping:

2500/Tape & Reel

Description:

The MC74HC393A is a dual 4-stage binary ripple counter with high-performance silicon-gate CMOS technology. It features two independent 4-bit binary ripple counters with parallel outputs from each counter stage. The device is designed for high noise immunity and low input current, making it suitable for a wide range of applications.

Features:

Output Drive Capability: 10 LSTTL Loads
Outputs Directly Interface to CMOS, NMOS, and TTL
Operating Voltage Range: 2.0 to 6.0V
Low Input Current: 1µA
High Noise Immunity Characteristic of CMOS Devices
In Compliance with the JEDEC Standard No. 7A Requirements
Chip Complexity: 236 FETs or 59 Equivalent Gates
Pb-Free, Halogen-Free, and RoHS Compliant
