RClamp0504FA Datasheet Summary

Basic Information

• Part Number: RClamp0504FA
• Manufacturer: Semtech Corporation
• Website: www.semtech.com
• Revision Date: 4/15/2010
• Package Type: SC-70, 6-pin

Description

The RClamp0504FA is a low capacitance TVS (Transient Voltage Suppressor) array designed to protect high-speed data interfaces. It is specifically designed to protect sensitive components connected to data and transmission lines from overvoltage caused by ESD (electrostatic discharge), CDE (Cable Discharge Events), and EFT (electrical fast transients). The device incorporates surge-rated, low capacitance steering diodes and a TVS diode in a single package, allowing it to absorb large amounts of energy while protecting downstream components from harmful transient events.

Features

• Low Capacitance: <3 pF for high-speed interfaces
• High ESD Surge Capability: Meets IEC 61000-4-2, Level 4 (15kV air, 8kV contact discharge)
• Small Package: 2.4 x 2.2 mm SC-70 package
• Protects up to Four I/O Lines and Power Line
• Low Leakage Current and Clamping Voltage
• Low Operating Voltage: 5.0 V
• Solid-State Silicon-Avalanche Technology
• Pb-Free, Halogen Free, RoHS/WEEE Compliant
• UL 94V-0 Flammability Rating
• Packaging: Tape and Reel

Applications

• USB 2.0
• USB OTG
• Monitors and Flat Panel Displays
• Digital Visual Interface (DVI)
• SIM Ports
• IEEE 1394 Firewire Ports

Absolute Maximum Ratings (T = 25°C)

• Reverse Stand-Off Voltage (VRWM): 5 V to 6 V
• Reverse Breakdown Voltage (VRB): 5 V to 6 V @ It = 1 mA
• Reverse Leakage Current (IR): 3 µA @ VRWM = 5 V, T = 25°C
• Clamping Voltage (VC): 15 V @ IPP = 1 A, tp = 8/20 µs
• Clamping Voltage (VC): 25 V @ IPP = 6 A, tp = 8/20 µs
• Capacitance (C): 3 pF @ VR = 0 V, f = 1 MHz (I/O to I/O)
• Capacitance (C): 1.5 pF @ VR = 0 V, f = 1 MHz (Between I/O and Ground)
• Peak Pulse Power (PPP): 150 W @ tp = 8/20 µs
• Peak Pulse Current (IPP): 6 A @ tp = 8/20 µs
• ESD Rating: ±15 kV (air), ±8 kV (contact) per IEC 61000-4-2
• Operating Temperature (TJ): -55 to +125 °C
• Storage Temperature (TSTG): -55 to +150 °C

Electrical Characteristics (T = 25°C)

• Reverse Stand-Off Voltage (VRWM): 5 V to 6 V
• Reverse Breakdown Voltage (VRB): 5 V to 6 V @ It = 1 mA
• Reverse Leakage Current (IR): 3 µA @ VRWM = 5 V, T = 25°C
• Clamping Voltage (VC): 15 V @ IPP = 1 A, tp = 8/20 µs
• Clamping Voltage (VC): 25 V @ IPP = 6 A, tp = 8/20 µs
• Capacitance (C): 3 pF @ VR = 0 V, f = 1 MHz (I/O to I/O)
• Capacitance (C): 1.5 pF @ VR = 0 V, f = 1 MHz (Between I/O and Ground)

Typical Characteristics

• Non-Repetitive Peak Pulse Power vs. Pulse Time: Up to 150 W @ tp = 8/20 µs
• Clamping Voltage vs. Peak Pulse Current: Increases with current, up to 25 V @ 6 A
• Capacitance vs. Reverse Voltage: Normalized to 0 V, up to 3 pF @ f = 1 MHz
• Insertion Loss (S21): Minimal loss up to 2.0 GHz
• Analog Crosstalk: Low crosstalk at high frequencies

Device Connection Options

• Protection of Data Lines and Power Line: Connect pin 5 to the positive supply rail (VCC)
• Internal TVS as Reference: Connect pin 5 to the internal TVS for supply isolation
• Complete Supply Isolation: Connect VCC to one of the I/O inputs and leave pin 5 unconnected

Applications Information

• SIM Port Protection: Protects three data lines and VCC
• USB OTG Carkit Protection: Protects USB data lines and VBus
• IEEE 1394 Firewire Protection: Protects high-speed data lines

Mechanical Characteristics

• Package: SC-70, 6-pin
• Lead Finish: Matte Tin
• Dimensions: 2.4 x 2.2 mm
• Flammability Rating: UL 94V-0

Ordering Information

• Part Number: RClamp0504FATCT
• Quantity per Reel: 3,000
• Reel Size: 7 inches
• Date Code: YYWW

Contact Information

• Semtech Corporation Protection Products DivisionAddress: 200 Flynn Rd., Camarillo, CA 93012Phone: (805) 498-2111Fax: (805) 498-3804
