6N136-500E Datasheet Summary

Product Overview

• Family: Single-Channel, High-Speed Optocouplers
• Model: 6N136
• Package: 8-Pin DIP
• Lead-Free: RoHS Compliant

Key Features

• High Speed: 1 Mb/s
• TTL Compatible: Suitable for TTL/CMOS, TTL/LSTTL applications
• Package Options: Available in 8-pin DIP, SO-8, and Widebody packages
• Open Collector Output: Provides flexibility in circuit design
• Safety Approval: UL Recognized, CSA Approved, IEC/EN/DIN EN 60747-5-5 Approved
• Minimum Current Transfer Ratio (CTR): 19% at IF = 16 mA

Applications

• High Voltage Insulation: Ideal for applications requiring electrical isolation.
• Video Signal Isolation: Ensures signal integrity in video applications.
• Line Receivers: Enhances signal reception in communication lines.
• Feedback Element in Switched Mode Power Supplies: Provides reliable feedback for power supply regulation.
• High-Speed Logic Ground Isolation: Suitable for TTL/TTL, TTL/CMOS, TTL/LSTTL applications.
• Replaces Pulse Transformers: Offers a compact alternative.
• Replaces Slow Phototransistor Isolators: Provides faster performance.
• Analog Signal Ground Isolation: Ensures signal integrity in analog applications.

Ordering Information

• Part Number: 6N136
• Package: 8-Pin DIP
• Option: -500E
• Quantity: 1000 per reel
• UL Recognition: 3750 Vrms for 1 minute per UL1577
• IEC/EN/DIN EN 60747-5-5 Approval: Ensures compliance with international safety standards.

Package Outline Drawing

• 8-Pin DIP Package: Dimensions provided in millimeters and inches, suitable for through-hole mounting.
• Lead Profile: Designed to be compatible with standard through-hole processes.

Absolute Maximum Ratings

• Storage Temperature (TS): -55°C to 125°C
• Operating Temperature (TA): -55°C to 100°C
• Average Forward Input Current (IF(AVG)): 25 mA
• Peak Forward Input Current (IF(PEAK)): 50 mA (50% duty cycle, 1 ms pulse width)
• Peak Transient Input Current (IF(TRANS)): 1 A (≤ 1 µs pulse width, 300 pps)
• Reverse LED Input Voltage (VR): 5 V
• Input Power Dissipation (PIN): 45 mW
• Average Output Current (IO(AVG)): 8 mA
• Peak Output Current (IO(PEAK)): 16 mA
• Emitter-Base Reverse Voltage (VEBR): 5 V
• Supply Voltage (VCC): -0.5 V to 15 V
• Output Voltage (VO): -0.5 V to 15 V
• Base Current (IB): 5 mA
• Output Power Dissipation (PO): 100 mW
• Lead Solder Temperature (TLS): 260°C (1.6 mm below seating plane, 10 seconds)

Electrical Specifications (DC)

• Current Transfer Ratio (CTR): 19% to 50% at IF = 16 mA, VCC = 4.5 V
• Logic Low Output Voltage (VOL): 0.1 V to 0.4 V at IO = 1.1 mA
• Logic High Output Current (IOH): 0.003 µA to 0.5 µA at VO = VCC = 5.5 V
• Logic Low Supply Current (ICCL): 50 µA to 200 µA at IF = 16 mA, VO = Open, VCC = 15 V
• Logic High Supply Current (ICCH): 0.02 µA to 1 µA at IF = 0 mA, VO = Open, VCC = 15 V
• Input Forward Voltage (VF): 1.5 V to 1.7 V at IF = 16 mA
• Input Reverse Breakdown Voltage (BVR): 5 V at IR = 10 µA
• Input Capacitance (CIN): 60 pF at f = 1 MHz, VF = 0 V

Switching Specifications (AC)

• Propagation Delay Time to Logic Low (tPHL): 0.2 µs to 1.5 µs at RL = 4.1 kΩ
• Propagation Delay Time to Logic High (tPLH): 1.3 µs to 2.0 µs at RL = 4.1 kΩ
• Common Mode Transient Immunity (CMH/CML): 1 kV/µs at VCM = 10 Vp-p, CL = 15 pF

Package Characteristics

• Input-Output Momentary Withstand Voltage (VISO): 3750 Vrms for 1 minute (RH < 50%, TA = 25°C)
• Input-Output Resistance (RI-O): 10^12 Ω at VI-O = 500 Vdc
• Input-Output Capacitance (CI-O): 0.6 pF at f = 1 MHz

Additional Notes

• Thermal Derating Curve: Provides guidelines for operating under different temperature conditions.
• Test Circuits: Includes switching test circuits and transient immunity test setups.
