Name: HCPL-060L-000E
Brand: Broadcom Limited
SKU: JM-HCPL-060L-000E
Availability: InStock

Broadcom Limited HCPL-060L-000E

View All Logic Output Optoisolators by Broadcom Limited

Part Number:
HCPL-060L-000E
Manufacturer:
Broadcom Limited
Category:
Logic Output Optoisolators
RoHs:
RoHS Compliant
Datasheet:
HCPL-060L-000E_Datesheet
Description:
Logic Output Optoisolator 15MBd Open Collector, Schottky Clamped 3750Vrms 1 Channel 10kV/µs CMTI 8-SO Tall
In stock 625

" Not available to buy online? Want the lower wholesale price? Please send RFQ, we will respond immediately

Leave Us A Message!

[email protected]

We`re not around but we still want to hear from you! Leave us a note:

SEND

*You can contact us directly on WhatsApp!

Specifications

Type

Paramete

Type

Paramete

Rise / Fall Time (Typ)

24ns, 10ns

Voltage - Supply

2.7V ~ 3.6V, 4.5V ~ 5.5V

Input Type

Base Product Number

HCPL-060

Common Mode Transient Immunity (Min)

10kV/µs

Mounting Type

Surface Mount

Inputs - Side 1/Side 2

1/0

Voltage - Isolation

3750Vrms

Data Rate

15MBd

Package / Case

8-SOIC (0.154", 3.90mm Width)

Supplier Device Package

8-SO Tall

Current - Output / Channel

50 mA

Voltage - Forward (Vf) (Typ)

1.5V

Output Type

Open Collector, Schottky Clamped

Propagation Delay tpLH / tpHL (Max)

75ns, 75ns

Number of Channels

Operating Temperature

-40°C ~ 85°C

Current - DC Forward (If) (Max)

20mA
