DESCRIPTION

· The TPD2EUSB30, TPD2EUSB30A, and TPD4EUSB30 are 2 and 4 channel TVS-based ESD protection diode arrays.

· These devices dissipate ESD strikes at the maximum level specified in IEC 61000-4-2 (Contact).

· They offer 5 A (8/20 μs) peak pulse current ratings per IEC 61000-4-5 (Surge) specification.

· The TPD2EUSB30A features a low 4.5-V DC breakdown voltage.

· Low capacitance, low breakdown voltage, and low dynamic resistance make these devices ideal for high-speed differential IOs.

· Available in space-saving DRT (1 mm × 1 mm) and DQA (2.5 mm × 1.0 mm) packages.

FEATURES

· Supports USB 3.0 data rates (5 Gbps).

· IEC 61000-4-2 ESD protection (level 4 contact).

· IEC 61000-4-5 surge protection –5 A (8/20 µs).

· Low capacitance: DRT: 0.7 pF (typical), DQA: 0.8 pF (typical).

· Dynamic resistance: 0.6 Ω (typical).

· Space-saving DRT, DQA packages.

· Flow-through pin mapping.

APPLICATIONS

· Notebooks.

· Set-top boxes.

· DVD players.

· Media players.

· Portable computers.
