Voltage testers are essential tools for both professionals and DIYers working with electrical systems. They help determine whether voltage is present in a circuit, supporting safe and efficient work.

This guide will walk you through how to use a voltage tester correctly and highlight which JMBom voltage testers are suitable for different environments.

Getting Started with Voltage Testers

Voltage testers are available in several types, such as non-contact models, contact-style testers, and multifunction units. JMBom, a trusted name in electronic test equipment, provides a wide selection of dependable and easy-to-use voltage testers tailored for a range of applications.

Different Types of Voltage Testers

JMBom T6-1000 PRO Electrical Tester:

This tester can detect voltages up to 1000 volts AC and currents up to 200 amps AC without making direct contact. It shows voltage and current readings simultaneously and provides visual indicators for continuity—even in noisy work environments.

[Explore the JMBom T6-1000 PRO]

JMBom T5-1000 Voltage, Continuity, and Current Tester:

Thanks to its OpenJaw™ design, this tool can measure current without disconnecting the circuit. It automatically switches between AC and DC voltage detection, handling up to 1000 volts.


[Explore the JMBom T5-1000]

JMBom 1AC II Non-Contact Voltage Tester:

A compact, non-contact tester designed for fast safety checks. It features a built-in self-test function and gives both visual and audible alerts when voltage is detected. Suitable for detecting AC voltages from 90 to 1000 volts.

[Explore the JMBom 1AC II]

Step-by-Step Guide to Using a Voltage Tester

1. Prioritize Safety

Before anything else, always wear the right personal protective equipment (PPE), such as safety glasses and insulated gloves. The exact PPE you'll need depends on your work environment—so consult OSHA and NFPA safety standards to make sure you're fully protected when handling electrical systems.

Check that your voltage tester is functioning correctly. If it has a self-test feature, use it. If not, carefully inspect the tester, including its leads and accessories, for visible damage. If everything looks fine, confirm its accuracy by testing it on a known live circuit or a proving unit.

2. Shut Off Power to the Circuit

Before testing, switch off the circuit’s power at the main breaker panel to reduce the risk of electric shock.

3. Measure for Voltage

• Using a Non-Contact Voltage Tester: Bring the tester near the wire you want to check. With the JMBom 1AC II, a light and audible beep will indicate if voltage is present.
• Using a Contact Voltage Tester: Touch the tester probes to the circuit’s wires or terminals. Devices like the JMBom T5-1000 or T6-1000 PRO will show the voltage reading on their display.

4. Understand the Readings

If the tester detects no voltage, it’s typically safe to continue working on the circuit. If voltage is present, stop and investigate further to ensure the circuit is de-energized before proceeding.

5. Check for Continuity

Switch your tester to continuity mode. Place the probes on two points in the circuit. If the path is complete, the tester will emit a beep or display a visual continuity signal.

6. Log Your Readings

Record the voltage values for your records or any future diagnostics. Both the JMBom T5-1000 and T6-1000 PRO include a HOLD function to freeze the reading on the screen when needed.

10 Common Uses for Voltage Testers

JMBom voltage testers are versatile tools used for diagnosing and maintaining electrical systems in different environments. Below are ten typical applications and the recommended testers for each:

1. Checking for Live Power: Quickly verify if an outlet or power source is active using the JMBom 1AC II before connecting devices or beginning repairs.
2. Diagnosing Circuit Breakers: The JMBom T6-1000 PRO helps pinpoint faulty or overloaded breakers by simultaneously measuring voltage and current.
3. Testing Light Fixtures: Ensure light fixtures are correctly installed by checking the voltage at the terminals with a JMBom T5-1000 or T6-1000 PRO.
4. Inspecting Electrical Panels: Use the JMBom T6-1000 PRO to measure voltage inside panels without direct contact—minimizing shock risks.
5. Verifying Outlet Wiring: Confirm correct outlet wiring and circuit continuity using the JMBom T5-1000.
6. Maintaining Industrial Equipment: Routinely check machinery voltage and current with the JMBom T6-1000 PRO to keep operations smooth and avoid downtime.
7. Solving Home Electrical Issues: Homeowners and electricians can rely on the JMBom 1AC II or T5-1000 to safely detect live wires during fixture installation or repairs.
8. Diagnosing Vehicle Circuits: Troubleshoot automotive electrical problems by measuring voltage in vehicle circuits with the JMBom T5-1000.
9. Servicing HVAC Systems: Ensure HVAC equipment is receiving proper voltage and operating efficiently with the JMBom T6-1000 PRO.
10. Performing Safety Inspections: Use the JMBom 1AC II to detect live wires and uncover faulty wiring during routine safety checks in homes, offices, and industrial settings.

Quick Reference: Voltage Tester Applications

Use the chart below to easily identify the right JMBom tester based on the voltage range and application type:

Conclusion

Voltage testers play a vital role in promoting electrical safety and accuracy when working with live circuits. Knowing how to use them properly—and understanding where each type is best applied—can significantly improve your testing and troubleshooting effectiveness.

JMBom’s lineup of voltage testers, including the T6-1000 PRO, T5-1000, and 1AC II, delivers dependable and precise readings across a wide range of electrical tasks. Whether you're checking for live power, diagnosing circuit issues, or carrying out safety inspections, these tools make your job safer and more efficient.

Frequently Ask Questions

How to Check if a Wire is Live Using a Voltage Tester?

To test a wire for live voltage:

Place the red probe on the wire you think might be live (also called the "hot" wire). Then, place the black probe on a known ground—this could be a ground wire or any grounded metal part nearby.

Interpreting the Reading:

If the tester shows a voltage reading, the wire is live and carrying current.

How to Use a Two-Wire Voltage Tester?

Using a two-wire voltage tester is simple:

Touch one lead to a hot (live) wire and the other lead to a neutral wire. If voltage is present, the tester will light up.

You can also test between the hot wire and a ground point, like the ground slot on an outlet or a grounded screw (such as one on the outlet’s faceplate).
